Supported resolutions: max. 8.3 Mpx - 3840 x 2160 px 4K UHD ; Audio support: 8 Channels ; Image compression method: H.265+ / H.265 ; Supported hard drives: 1 x 10 TB SATA ; Intelligent Image Analysis;
| Standard: | TCP/IP |
| Supported resolutions: | max. 8.3 Mpx - 3840 x 2160 px 4K UHD |
| Video outputs: | 1 pcs HDMI 4K 1 pcs VGA |
| Audio support: | 8 Channels - Audio from cameras |
| Audio inputs: | 1 pcs CINCH |
| Audio outputs: | 1 pcs CINCH |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Supported hard drives: | 1 x 10 TB SATA |
| Recording modes: | Manual, Motion Detection, Schedule |
| Network protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, Alarm Server, IP Search, P2P, ONVIF |
| External storage devices backup: | Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: | Records searching: by time and events type. Records playback: forward, backward, fast, slow Advanced searching (to the one second accuracy) All channels synchronous playback, Smart Search function |
| Bitrate: | max. 80 Mbps |
| Network functions: | |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Default IP address: | 192.168.1.108 |
| Web browser access ports: | 80, 37777 |
| PC client access ports: | 37777 |
| Mobile client access ports: | 37777 |
| RTSP URL: | rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| ONVIF: |  |
| Mobile phones support: | Port no.: 8000 or access by a cloud (P2P) |
| Alarm inputs / outputs: |  |
| PTZ control: | IP Speed Dome Cameras |
| USB: | 2 pcs USB 2.0 |
| Intelligent Image Analysis: | |
| Motion Detection: | |
| Main features: | Functions implemented in cooperation between the recorder and cameras that support these functions |
| Mouse support: | |
| IR remote controller in the set: | |
| Operation temp: | -10 °C ... 50 °C |
| Switch PoE: | 4-port PoE Switch built-in, 25.5 W / Channel |
| Maximum total switch load: | 72 W |
| Power supply: | 48 V DC / 1.81 A (power adapter included) |
| Weight: | 0.7 kg |
| Dimensions: | 270 x 205 x 15 mm |
| Supported languages: | English, Polish |
| Country of origin: | China |
| Manufacturer / Brand: | BCS Line |
| Guarantee: | 3 years |
Brand:
BCS
