• IP-видеовход 16 каналов (IP) • Количество и скорость портов PoE: 8 x RJ-45 10M/100M. • Максимальная мощность PoE 75 Вт. •Видео выход • VGA-HDMI (4K)
AUDIO PARAMETERS
Audio output 1 channel (RCA) + IPC
RECORDING AND DECODING PARAMETERS
Compression H.264 H.265 Ultra265
Maximum digital recording resolution 8MP
Maximum digital decoding
1 channel 30 FPS (at maximum resolution)
Digital decoding Options: 1 x 4k@30, 1 x 5MP@30, 2 x 4MP@30, 4 x 3MP@25, 4 x 1080p@30, 8 x 720p@30, 16 x D1@25
Data flow Incoming (Mbit): 64 Outgoing (Mbit): 48
ANALYTICS Analytics From IP cameras (camera side)
INTERFACE PARAMETERS
Network ports
1 x RJ-45 10M/100M
USB ports
2 x USB2.0
ARCHIVE PARAMETERS
Number of SATA interfaces 1
SATA Capacity Up to 10TB per drive
COMMON PARAMETERS
Material Plastic
Power supply unit Included
Power supply DC52V
Dimensions and weight Length (mm): 270 Width (mm): 205 Height (mm): 46 Weight (g): 800
Power Maximum power (W): 9
