NVR equipped with advanced functions of intelligent image analysis; Supported resolutions: max. 32 Mpx ; Audio support: 16 Channels - Audio from cameras ; Audio inputs: 1 pcs CINCH ; Audio outputs: 1 pcs CINCH ; Image compression method: Smart H.265+ ; Supported hard drives: 2 x 16 TB SATA ; Main features: Intelligent Image Analysis, face detection ;
| Standard: | TCP/IP |
| Supported resolutions: | max. 32 Mpx |
| Video outputs: | 1 pcs HDMI 4K 1 pcs VGA |
| Audio support: | |
| Audio inputs: | 1 pcs CINCH |
| Audio outputs: | 1 pcs CINCH |
| Image compression method: | Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG |
| Bitrate: | max. 384 Mbps |
| Supported hard drives: | 2 x 16 TB SATA |
| Recording modes: | Manual, Sensor, Motion detection, Schedule |
| External storage devices backup: | Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: | |
| Network interface: | 1 x RJ-45 10/100/1000 Base-TX |
| Network functions: | Full support via network, Remote records copying, Web-Server built-in |
| Network protocols: | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, P2P, Auto Register |
| ONVIF: | 21.12 |
| Default IP address: | 192.168.1.108 |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Mobile phones support: | Port no.: 37777 or access by a cloud (P2P) See how to configure the P2P function in Dahua recorders and how to enable the mobile application |
| Web browser access ports: | 80, 37777 |
| PC client access ports: | 37777 |
| Mobile client access ports: | 37777 |
| RTSP URL: | |
| USB: | |
| Serial ports: | RS-485, RS-232 |
| Alarm inputs / outputs: | 4 / 2 |
| PTZ control: | |
| Motion Detection: |  |
| Intelligent Image Analysis: | |
| Main features: | Functions implemented in cooperation between the recorder and cameras that support these functions : |
| Mouse support: | |
| IR remote controller in the set: |  |
| Power supply: | 12 V DC / 4 A (power adapter included) |
| Power consumption: | max. 10 W (without HDD) |
| Operation temp: | -10 °C ... 55 °C |
| Weight: | 1.53 kg |
| Dimensions: | 375 x 284 x 55 mm |
| Supported languages: | Polish, English, Bulgarian, Czech, Finnish, Greek, Romanian, Serbian, Slovenian, Hungarian |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 3 years |
Brand:
Dahua
