Supported resolutions: max. 12 Mpx - 4000 x 3000 px ; Audio support: 16 Channels, Bi-directional audio streaming support ; Image compression method: H.265+ ; Supported hard drives: 1 x 10 TB SATA ; Intelligent Image Analysis: Support for intelligent image analysis, available in cameras from the APTI-AI series ;
| Standard: | IP |
| Supported resolutions: | max. 12 Mpx - 4000 x 3000 px |
| Video outputs: | |
| Audio support: | |
| Audio inputs: | 1 pcs CINCH |
| Audio outputs: | 1 pcs CINCH |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 |
| Bitrate: | 128 Mbps (incoming) |
| Supported hard drives: | 1 x 10 TB SATA |
| Recording modes: | Manual, Motion Detection, Schedule |
| External storage devices backup: | Backup to USB drive (pendrive, external drive) |
| Searching and playback the records: | Records searching: by time and events type. Records playback: forward, backward, fast, slow Channels played simultaneously : 1 @ 12 Mpx, 30 fps 1 @ 8 Mpx, 30 fps 2 @ 5 Mpx, 30 fps 4 @ 4 Mpx, 30 fps 7 @ 1080p, 30 fps 16 @ 720p, 30 fps |
| Network interface: | 1 x RJ-45 10/100/1000 Base-TX |
| Network functions: | Network Client Software and IE browser: live view, playback and backup of the records, configuration of the recorder parameters |
| ONVIF: |  |
| Default IP address: | DHCP / 192.168.1.88 |
| Default admin user / password: | admin / 12345 |
| Mobile phones support: | Access by a cloud (P2P) |
| Web browser access ports: | 80, 5000, 554 |
| PC client access ports: | 80, 5000, 554 |
| USB: | 2 pcs USB 2.0 |
| Serial ports: |  |
| Alarm inputs / outputs: | |
| PTZ control: | IP Speed Dome Cameras |
| Motion Detection: | Split the screen into zones : 22 x 18 motion zones |
| Intelligent Image Analysis: | Support for intelligent image analysis, available in cameras from the APTI-AI series |
| Main features: | |
| Mouse support: | |
| IR remote controller in the set: | |
| Switch PoE: | 8-port PoE Switch built-in : 30 W / Channel - PoE (802.3at) |
| Maximum total switch load: | 72 W |
| Power supply: | 48 V DC / 1.87 A (power adapter included) |
| Power consumption: | max. 10 W (without HDD & PoE) |
| Operation temp: | -10 °C ... 50 °C |
| Weight: | 0.94 kg |
| Dimensions: | 260 x 230 x 43 mm |
| Supported languages: | Polish, English, Czech, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Ukrainian, Hungarian, Italian |
| Manufacturer / Brand: | APTI |
| Guarantee: | 2 years |
Brand:
Apti
