Sensor: 1/1.8 " Progressive Scan CMOS ; Resolution: 2688 x 1520, 1600 × 1200, 1920 x 1080, 1280 x 720 ; Lens: - Motozoom ; White light LED illuminator range: 30 m ; Alarm inputs / outputs: 3 / 3 ; Audio: Bi-directional audio streaming support ; RS-485 interface: 2 ; Power supply: PoE (802.3at), 12 V DC ; "Index of Protection": IP67 ;
Standard: | IP |
Sensor: | 1/1.8 " Progressive Scan CMOS |
Matrix size: | 4 Mpx |
Resolution: | 2688 x 1520 - 4 Mpx , 1600 × 1200 - 2 Mpx , 1920 x 1080 - 1080p , 1280 x 720 - 720p |
Lens: | 10 ... 50 mm - Motozoom |
View angle: | 41 ° ... 9 ° |
White light LED illuminator range: | 30 m |
Compression: | H.265 / H.264H / H.264M |
Main stream frame rate: | 25 fps - 4 Mpx |
Network interface: | 100/1000 Base-T (RJ-45) |
WEB Server: | Built-in |
Memory card slot: | Micro SD card support up to 128GB |
Alarm inputs / outputs: | 3 / 3 |
Audio: | |
RS-485 interface: | 2 |
RS-232 interface: | 1 |
Mobile phones support: | ![]() |
Main features: | |
Power supply: | |
Power consumption: | < 20 W |
Housing: | Compact, Metal + Plastic |
Color: | White + Black |
"Index of Protection": | IP67 |
Vandal-proof: | ![]() |
Operation temp: | -30 °C ... 65 °C |
Weight: | 2.30 kg |
Dimensions: | 371 x 125 x 106 mm |
Supported languages: | English |
Manufacturer / Brand: | DAHUA |
Guarantee: | 3 years |
