• 1/2.7" Progressive Scan CMOS • 2688 × 1520 @ 25fps • 1.68 mm ultra wide angle fixed lens • 120dB WDR • H.265, H.265+, H.264, H.264+ • Built-in micro SD/SDHC/SDXC card slot, up to 256 GB • IP67
|
Title |
Description |
|
Image Sensor |
1/2.7" Progressive Scan CMOS |
|
Min. Illumination |
0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
|
Shutter Speed |
1/3 s to 1/100,000 s |
|
Wide Dynamic Range |
120dB |
|
Day & Night |
ICR Cut |
|
Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
|
Focus |
Fixed |
|
Lens Type & FOV |
1.68mm @ F2.0, horizontal FOV 180°, vertical FOV 101°, diagonal FOV 180° |
|
Aperture |
F2.0 |
|
Lens Mount |
M12 |
|
DORI |
Detect: 3.6 m, observe: 1.4 m, recognize: 0.8 m, identify: 0.4 m |
|
IR Range |
20 m |
|
Wavelength |
850nm |
|
Max. Resolution |
2688 × 1520 |
|
With Package Weight |
760 g (1.68 lb.) |
|
Class |
Class B |
|
Video Compression |
Main stream: H.265+/H.265/H.264+/H.264; Sub-stream: H.265/H.264 /MJPEG |
|
Video Bit Rate |
32 Kbps to 16 Mbps |
|
Scalable Video Coding (SVC) |
H.264, H.265 |
|
Network Storage |
micro SD/SDHC /SDXC (256 G) local storage, and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
|
Client |
iVMS-4200, Hik-Connect, Hik-Central |
|
Web Browser |
Plug-in free live view: Chrome45.0+, Firefox52.0+ Local service: Chrome41.0+, Firefox30.0+ |
|
Day/Night Switch |
Day, Night, Atuo, Schedule |
|
On-board Storage |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
|
Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
|
Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
|
Power Supply |
12 VDC ± 25%; PoE: 802.3af, Class 3 |
|
Power Consumption and Current |
12 VDC, 0.6 A, max. 7.2W PoE: (802.3af, 36 V-57 V), 0.3 A to 0.2 A, max. 8.7W |
|
Power Interface |
Φ5.5 mm coaxial power plug |
|
Material |
Metal |
|
Camera Dimension |
Camera: Φ105 × 278 mm (Φ4.1″ × 10.9″) |
|
Protection |
IP67 |
