• H.265+/H.265/H.264+/H.264 encoding for the main stream, and H.265/H.264 for the sub-stream of analog cameras • Self-adaptive HDTVI/HDCVI/AHD/CVBS signal input • Connectable to H.265+/H.265/H.264+/H.264 IP cameras • Up to 3 MP resolution for recording • HDMI output at up to 4K (3840 × 2160) resolution for DS-7216HQHI-K1 • Long distance transmission over UTP and coaxial cable • 4/8/16-ch synchronous playback
|
Video/Audio Input |
|
|
Audio Input: |
1-ch |
|
Video Compression: |
H.265+/H.265/H.264+/H.264 |
|
Analog and HD-TVI video input: |
4-ch,BNC interface (1.0Vp-p, 75 Ω)connection |
|
Supported camera types: |
Support HDTVI input: 3MP,1080P/25Hz, 1080P/30Hz,720P/25Hz, 720P/30Hz, 720P/50Hz, 720P/60Hz, |
|
Support AHD input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz |
|
|
Support CVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz |
|
|
Support CVBS input |
|
|
Video Input Interface: |
BNC (1.0 Vp-p, 75Ω) |
|
Audio Compression: |
G.711u |
|
Audio Input Interface: |
RCA (2.0 Vp-p, 1 kΩ) |
|
Two-way Audio: |
1-ch, RCA (2.0 Vp-p, 1 KΩ), (using the 1st channel of audio input) |
|
Video/Audio Output |
|
|
CVBS Output: |
1-ch,BNC(1.0Vp-p,75Ω),resolution:PAL:704x576,NTSC:704x480 |
|
HDMI/VGA Output: |
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
|
Recording resolution: |
When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF; |
|
When 1080p Lite mode enabled: 1080p lite/720p lite/VGA/WD1/4CIF/CIF |
|
|
Frame Rate: |
Main stream: |
|
When 1080p Lite mode not enabled: |
|
|
For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps |
|
|
For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
|
|
For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
|
|
When 1080p Lite mode enabled: |
|
|
3 MP@15fps |
|
|
1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) |
|
|
Sub-stream: |
|
|
WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) |
|
|
Video Bit Rate: |
32 Kbps-6 Mbps |
|
Stream Type: |
Video/Video&Audio |
|
Two-way Audio: |
1-ch, RCA (2.0 Vp-p, 1 kΩ) (using the audio input) |
|
Audio Output: |
1-ch RCA(Linear, 1kΩ) |
|
Audio Bit Rate: |
64kbps |
|
Dual Stream: |
Support |
|
Playback Resolution: |
3 MP/1080p/720p/VGA/WD1/4CIF/CIF |
|
Synchronous Playback: |
4-ch |
|
Network management |
|
|
Remote connections: |
128 |
|
Network protocols: |
TCP/IP, PPPoE, DHCP, Hik-connect Cloud P2P,DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS,ONVIF |
|
Hard Disk Driver |
|
|
Interface Type: |
1 SATA Interface |
|
Capacity: |
Up to 6 TB capacity for each disk |
|
External Interface |
|
|
Network Interface: |
1; 10M / 100M self-adaptive Ethernet interface |
|
USB Interface: |
2 USB 2.0 Interfaces |
|
Serial Interface: |
1; standard RS-485 serial interface, half-duplex |
|
General |
|
|
Power Supply: |
12V DC |
|
Consumption: |
≤ 6W(without hard disks) |
|
Working Temperature: |
-10 ºC to +55 ºC (14 ºF to 131 ºF) |
|
Working Humidity: |
10% to 90% |
|
Dimensions: |
315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
|
Weight: |
≤ 1.16 kg (2.6 lb) |
