AHD, HD-CVI, HD-TVI, CVBS, IP DVR IDS-7204HUHI-M1/S(C) 4 CHANNELS AcuSense Hikvision

€90.99

(Включая налог 21%)

Задать вопрос

КОД: IDS-7204HUHI-M1/S(C)

Доступность: 29 шт.

Кол-во:

+ −

Минимальное количество для товара "AHD, HD-CVI, HD-TVI, CVBS, IP DVR IDS-7204HUHI-M1/S(C) 4 CHANNELS AcuSense Hikvision" 1.

Купить в один клик

Описание
Особенности

Audio inputs: 1 pcs CINCH, Coaxial audio - Audio from cameras ; Image compression method: H.265+ ; Image records resolutions: HD-TVI : 8 Mpx - 3840 x 2160 1 CH only, 8M-N - 1920 x 2160 2,3,4 CH only, 5 Mpx - 2560 x 1944, 3.7 Mpx - 2560 x 1440, 3 Mpx - 1920 x 1536, AHD : 5 Mpx - 2560 x 1944, 3.7 Mpx - 2560 x 1440, HD-CVI : 3.7 Mpx - 2560 x 1440, IP : max. 8 Mpx - 3840 x 2160 ; Supported hard drives: 1 x 10 TB SATA ;

Standard:	AHD, HD-CVI, HD-TVI, CVBS, TCP/IP
Video inputs:	4 pcs BNC - AHD / HD-CVI / HD-TVI / CVBS
Video outputs:	1 pcs HDMI 1 pcs VGA 1 pcs CVBS - BNC socket
Audio inputs:	1 pcs CINCH, Coaxial audio - Audio from cameras
Audio outputs:	1 pcs CINCH
Image compression method:	H.265+ / H.265 / H.264 / H.264+
Image records resolutions:	HD-TVI : 8 Mpx - 3840 x 2160 1 CH only , 8M-N - 1920 x 2160 2,3,4 CH only , 5 Mpx - 2560 x 1944 , 3.7 Mpx - 2560 x 1440 , 3 Mpx - 1920 x 1536 , 1080p - 1920 x 1080 , 720p - 1280 x 720 , AHD : 5 Mpx - 2560 x 1944 , 3.7 Mpx - 2560 x 1440 , 1080p - 1920 x 1080 , 720p - 1280 x 720 , HD-CVI : 3.7 Mpx - 2560 x 1440 , 1080p - 1920 x 1080 , 720p - 1280 x 720 , PAL : 960H - 960 x 576 , IP : max. 8 Mpx - 3840 x 2160
Recording speed adjustment:	8 Mpx IP @ 1 ... 25 fps 8 Mpx @ 1 ... 8 fps 8M-N @ 1 ... 15 fps 5 Mpx @ 1 ... 12 fps 4 Mpx @ 1 ... 15 fps 3 Mpx @ 1 ... 18 fps 1080p @ 1 ... 25 fps 720p @ 1 ... 25 fps 960H @ 1 ... 25 fps for each channel
Operation modes:	4 x HD-TVI / AHD / HD-CVI / CVBS / IP + 4 x IP
Recording modes:	Manual, Sensor, Motion detection, Schedule
Supported hard drives:	1 x 10 TB SATA
External storage devices backup:	Backup to USB drive (pendrive, external drive)
Searching and playback the records:	Records searching: timeline or file list. Playback: forward, fast, slow. Playback max. 4 cameras in the same time
Network interface:	1 x RJ-45 - 10/100 Base-TX
Bitrate:	32 ... 10240 kbps
Network functions:	Network Client Software and IE browser: live view, playback and backup of the records, partial configuration of the recorder parameters
Network protocols:	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Mobile phones support:	Port no.: 8000 or access by a cloud (P2P) Android: Hik-Connect free application iOS: Hik-Connect free application
Default IP address:	DHCP or 192.168.1.64
Default admin user / password:	admin / - The administrator password should be set at the first start
Web browser access ports:	80
PC client access ports:	554 RTSP, 8000
Mobile client access ports:	8000
ONVIF port:	80
RTSP URL:	rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no01/ - Main stream rtsp://user:password@192.168.1.64:554/Streaming/Channels/channel_no02/ - Sub stream
Alarm inputs / outputs:
PTZ control:	Control compatible with coax HD-TVI Hikvision RS-485 - PELCO-D/P
Motion Detection:	2.0
USB:	2 x USB 2.0
Mouse support:
IR remote controller in the set:
Main features:	DVR from the AcuSense series Intelligent Image Analysis : crossing the line (tripwire), intrusion, Deep Learning technology Smart motion detection (with recognizing people and vehicles) Filtering of false alarms based on the recognition of persons and vehicles
Power supply:	12 V DC / 1.5 A (power adapter included)
Color:	Black
Weight:	1.1 kg
Dimensions:	315 x 250 x 45 mm
Supported languages:	Polish, English, Bulgarian, Croatian, Czech, Danish, Estonian, Greek, Spanish, Dutch, German, Norwegian, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Hungarian, Italian
Manufacturer / Brand:	Hikvision
SAP Code:	300226972
Guarantee:	3 years
