Audio inputs: 1 pcs ; Image compression method: AI Coding / H.265+ ; Image records resolutions: AHD / HD-CVI / HD-TVI : 5M-N - 1296 x 1440, 4M-N - 1280 x 1440, IP : max. 8.3 Mpx 4K UHD - 3840 x 2160 ; Supported hard drives: 8 x 16 TB SATA ; Alarm inputs / outputs: 16 / 6 ; Main features: Cooperation with Dahua devices working in the concept of the Internet of Things (IoT), Coax Audio/Alarm support, Intelligent Image Analysis ;
| Standard: | AHD, HD-CVI, HD-TVI, CVBS, TCP/IP |
| Video inputs: | 16 pcs BNC |
| Video outputs: | 2 pcs HDMI 1 pcs VGA |
| Audio inputs: | 1 pcs - BNC socket - Microphone 16 pcs - BNC socket 16 - Audio support via coaxial cable, HD-CVI only |
| Audio outputs: | 1 pcs BNC socket |
| Image compression method: | AI Coding / H.265+ / H.265 / H.264+ / H.264 |
| Image records resolutions: | AHD / HD-CVI / HD-TVI : 5M-N - 1296 x 1440 , 4M-N - 1280 x 1440 , 1080p - 1920 x 1080 , 1080N - 960 x 1080 , 720p - 1280 x 720 , AHD / HD-TVI : 3M-N 1024 x 1536 , CVBS : 960H - 960 x 576 IP : max. 8.3 Mpx 4K UHD - 3840 x 2160 |
| Recording speed adjustment: | 8.3 Mpx IP @ 1 ... 25 fps 5M-N @ 1 ... 10 fps 4M-N @ 1 ... 15 fps 1080p @ 1 ... 15 fps 1080N @ 1 ... 25 fps 720p @ 1 ... 25 fps 960H @ 1 ... 25 fps for each channel |
| Operation modes: | 16 x AHD / HD-CVI / HD-TVI / CVBS / IP + 8 x IP |
| Recording modes: | Manual, Motion Detection, Schedule |
| Supported hard drives: | |
| External storage devices backup: | Save single frames and whole records from DVR drive to the USB drive |
| Searching and playback the records: | Records searching: by time + timeline with record type. Playback: forward, fast, slow, step Advanced searching (to the one second accuracy) Intelligent face search AI - simultaneous search in the archive of face recordings based on max 8 photos taking into account the similarity threshold (for each photo separately) 1/4/9/16 channel synchronous playback |
| Network functions: | Full support via network, Remote records copying, Web-Server built-in max. 128 on-line users |
| Mobile phones support: | Port no.: 37777 or access by a cloud (P2P) See how to configure the P2P function in Dahua recorders and how to enable the mobile application |
| Alarm inputs / outputs: | 16 / 6 |
| PTZ control: | IP Speed Dome Cameras Control compatible with coax PTZ HD-CVI RS-485 - PELCO-D/P |
| Motion Detection: | Split the screen into zones |
| Main features: | |
| USB: | 2 pcs USB 2.0 2 pcs USB 3.0 |
| Mouse support: |  |
| IR remote controller in the set: |  |
| Power supply: | 230 V AC |
| Color: | Black |
| Weight: | 6.7 kg |
| Dimensions: | 440 x 463 x 95 mm |
| Supported languages: | Polish, English, Czech, Danish, Finnish, French, Greek, Spanish, Dutch, German, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Hungarian, Italian |
| Country of origin: | China |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 5 years |
Brand:
Dahua
