Number of video outputs: 16 pcs BNC socket ; Number of power outputs: 16 pcs ; Maximal power supply current: 2x10 A ;
| Standard: | CVBS - PAL / NTSC |
| Number of video outputs: | 16 pcs BNC socket |
| Number of video inputs: | 16 pcs screw terminals |
| Number of power outputs: | 16 pcs Cable terminals |
| Number of power inputs: | 6 pcs 2.1/5.5mm socket / cable terminals |
| Maximal power supply current: | 2x10 A |
| Maximal current for single output: | 1 A |
| Type of fuses: | 1A/250V, 5/20mm, delayed |
| Power supply: | 8 ... 30 V DC (typical 12V) |
| Device current consumption (for different Uz): | 12 V = 150 mA / 30 V = 250 mA |
| LEDs application: | |
| Max. current: | |
| Assembly: | Rack 10" |
| Housing: | Metal |
| Color: | Black |
| Operation temp. / Relative humidity: | -50 °C ... 55 °C / < 95 % |
| Weight: | 0.6 kg |
| Dimensions: | 480 x 48 x 44 mm |
| Manufacturer / Brand: | DELTA |
| Guarantee: | 3 years |
Brand:
Delta
