Regulation Type: PWM ; Rated voltage: 12 / 24 / 36 / 48 / 60 V ; Rated current: 40 A ; Weight: 0.3 kg ;
| Regulation Type: | PWM |
| Rated voltage: | 12 / 24 / 36 / 48 / 60 V |
| Rated current: | 40 A |
| Permitted voltage range: | max. 18 V for 12 V battery - The range of the highest operating voltage of a set of panels connected to one input of the controller max. 36 V for 24 V battery - The range of the highest operating voltage of a set of panels connected to one input of the controller max. 54 V for 36 V battery - The range of the highest operating voltage of a set of panels connected to one input of the controller max. 72 V for 48 V battery - The range of the highest operating voltage of a set of panels connected to one input of the controller max. 90 V for 60 V battery - The range of the highest operating voltage of a set of panels connected to one input of the controller |
| Battery charging current: | max. 40 A |
| Load Current: | max. 20 A |
| Output voltage: | |
| Main features: | |
| Weight: | 0.3 kg |
| Dimensions: | 169 x 94 x 40 mm |
| Guarantee: | 2 years |
Brand:
Delta Power
